BOMBA ALTA PRESION

PVG-150-A1UV-RDFY-P-1NN/FSN-CP

PVG- = Pump, Variable `G` Series 150- = 150 mL/rev (9.16 in^3/rev) A1 = Design Series (Subject to Change) U = SAE Mounting and Ports (4 Bolt, SAE D, #16 SAE Case Drain) V- = Viton (Standard) R = Righthand (CW facing pump shaft) D = Top/Bottom Ported, Thru Shaft F = 2.50` Code 61 Suction, 1.25` Code 62 Pressure Y- = Keyed (SAE D, 1.75` DIA.) 1.75` Long Keyway P- = Pressure Compensating Control 1 = Single Pressure N = No Solenoid Voltage Required N = No Connector /F = Load Sense Option SN = Maximum Volume Stop (Standard) -CP = Cover Plate
